FJD LM01 Line Marker Kit — RM21 Attachment
FJD LM01 Line Marker Kit — RM21 Attachment
Priced per site
Coverage area, terrain, obstacle density and fleet size all change how this unit is configured, so we scope it rather than list a price. Tell us about the property and we'll come back with a specification and a quote.
Request a quoteOr call 416.848.0672 — we run these machines ourselves and can tell you quickly whether one fits your site.
Commercial pricing available to registered accounts. Register for pricing access →
Turns the RM21 into an autonomous line marker. Up to 20 full-size fields per charge.
The LM01 kit fits to the RM21 platform, so the same machine that mows the pitch also marks it. Layouts are stored digitally and recalled for every session, and the RM21's RTK positioning puts the lines where they were last time rather than where the string happened to fall.
FJD reports paint usage down by more than 50% and labour cost down by up to 90% against manual marking. On a multi-pitch site those are the two lines on the budget that marking actually shows up on.
WALLE Corp. is an authorized FJD Dynamics dealer. We ship anywhere in Canada, and we service the Greater Toronto Area and the Golden Horseshoe directly — Burlington, Oakville, Milton, Hamilton, Mississauga, Halton Hills, Waterdown, Dundas, Ancaster, Stoney Creek and Grimsby.
Deployment, fitting and operator training are included with every commercial attachment.
Specifications
| Weight | 68 kg · 150 lb |
| Dimensions | 1515 × 853 × 1051 mm |
| Max marking speed | 3 km/h · 1.9 mph |
| Paint tank | 25 L · 5.5 gal |
| Line width range | 50–170 mm · 2–6.7 in |
| Nozzle height | 30–80 mm · 1.2–3.1 in |
| Max marking time per charge | 20 hours |
| Fields per charge | Up to 20 full-size |
| IP rating | IPX4 |
| Operating temperature | 5–35°C |
Seamless resume
Whether it is switching fields or pausing to refill paint, the robot picks up precisely where it stopped. No overlapping, no double-painted segment, no wasted paint. That single behaviour is what makes unattended marking practical — otherwise every interruption costs a re-run.
Sports supported
Soccer, rugby, American football, baseball, lacrosse and custom layouts.
Requires an FJD RM21 platform. Priced per site — tell us about the facility and we will scope it.
